SMD to DIP adaptor board set (7)
SMD to DIP adaptor board set (7)
CALIFORNIA WARNING
This product can expose you to chemicals known to the State of California to cause cancer and reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
Product Details
7 piece set of SMD component to Through Hole breakout board st
Double sided .062", FR-4 board, plated copper pads. Mini adapter board kit converts surface mount components to thru hole mount. Pins available separately under related items below.
Package include these assorted size circuit boards:
8 Pin SOP/TSOP package with .65 or 1.27mm pitch to a 8 pin .1" pitch x .3" width (2.54mm X 7.52mm) DIP pattern.10 Pin SOP10/SOT23 package with .5 or .95mm pitch to a 10 pin .1" pitch X .3" width (2.54mm x 7.52mm) DIP pattern.14 Pin TSOP/SSOP/SOP/SOIC/SO .65 or 1.27mm pitch Flat Pack to a 14 pin .1" pitch X .6" width (2.54mm X 15.2mm) DIP pattern.16 Pin TSOP/SSOP/SOP/SOIC/SO .65 or 1.27mm pitch Flat Pack to a 16 pin .1" pitch X .5" width (2.54mm X 12.7mm) DIP pattern.20 Pin SO/SOP/SOIC/SSOP/TSSOP & MSOP .65 or 1.27mm pitch Flat Pack to a 20 pin .1" pitch X .6" width (2.54mm X 15.24mm) DIP pattern.24 Pin .65 or 1.27mm pitch SO/SOP/SOIC/SSOP/TSSOP & MSOP packages to a 24pin .1" pitch X .6" width (2.54mm X 15.24mm) DIP pattern.28 Pin .65 or 1.27mm pitch SO/SOP/SOIC/SSOP/TSSOP & MSOP packages to a 28 pin .1" pitch X .7" width (2.54mm X 18mm) DIP pattern.
