Computer platform Gottlieb System 1

The famous Pascal Janin designed All-in-One electronics system board replaces all backbox circuit boards inside Gottlieb® System 1 pinball machines. (CPU, driver, power supply, 3-tones sound board)

The FLIPPP! PI-1X4 board includes:

new power supply circuitnew driver circuit with integral coil and transistor protectionnew sound circuit with a built-in stereo amplifier

Supports all 16 original Gottlieb® System 1 games:

ASTEROID ANNIE
BUCK ROGERS
CHARLIE'S ANGELS
CLEOPATRA
CLOSE ENCOUNTERS
COUNTDOWN
DRAGON
GENIE
HULK
JOKER POKER
PINBALL POOL
SINBAD
SOLAR RIDE
TORCH
TOTEM
ROLLER DISCO

and European derivative kit games:
HELL'S QUEEN
SKY WARRIOR
SAHAR LOVE
JUNGLE QUEEN
L'HEXAGONE
MOVIE
TIGER WOMAN

FEATURES:

Professionally manufactured board with modern microprocessor and a concise list of available peripheral componentsDirect board-to-board replacement for the power supply (A2), the MPU (A1), driver board (A3) and 3-tones sound (A6) boards. No specific preliminary settings are required.Failure prone wire harnesses from A2J1 to A1J1 and A1J5 to A3J1 are eliminated.Single plug and play board fits all games, specific game PROMs are unnecessaryBuilt with modern, reliable components for easy, lower cost maintenanceSpecific software & hardware protections against most common failures (e.g. high voltage shorts from coils, etc)Active coil protection: coil drive current is monitored by sensor and relay to protect transistors & coils in case of short-circuits.Energy saving board with reliable, efficient power supply that won't overheat.LED indicators for CPU activity, multiple power supply voltages (60V/42V, 12V/8V, 5V) and active coils protectionNon-volatile game settings and bookkeeping memory -- no battery requiredSoftware selectable options with text style menus - no difficult to adjust DIP switchesConfiguration menus & various messages available in French, English, German, Portuguese, Italian & SpanishInstallation manual in English with fully detailed, simple explanations. Installation is easy even for novice technicians.

Reference:

PI-1X4
