Coin door assembly Stern SAM 4 button 40-0696-24
Coin door assembly Stern SAM 4 button
CALIFORNIA WARNING
This product can expose you to chemicals known to the State of California to cause cancer and reproductive harm. For more information, go to https://www.p65warnings.ca.gov.
Product Details
Stern SAM System style pinball machine coin door includes frame, coin mech holders, coin switches, 4 button diagnostic switches, coin slot lamps and sockets, lock and keys.
Coin mechanisms and wiring harness are included.
Standard OEM (original equipment manufacturer) two-slot replacement coin door for Stern pinball machines.
Door is secured to cabinet by: 1/4-20 x 1-1/4 inch square neck carriage bolt (Qty. 4) (231-5003-00) and 1/4-20 flange nut (Qty. 4) with (240-5300-00) fender washers 1/4" I.D. x 1" O.D. (Qty. 3)
Reference:
501-5018-172
Instructions for mounting optional upstacker bill validators:
This coin door will accommodate the following manufacturers' bill validators:
MEI model Series 2000 upstacker ICT model A6, S6, PAT Series upstackerr Pyramid model APEX 5000-U, XLC 5000-U series upstacker
1. Remove 2 bottom hex nuts (E & F) from bottom studs and remove 2 white spacers (retain both for later use)2. Remove 2 hex nuts (C & D) from middle studs3. Remove the blanking plate from the door4. Place the 2 white spacers removed in step #1 over the 2 long studs at the bottom of the door (E & F).5. Remove the 2 top hex nuts (A & B) from top long studs and keep the existing 2 white spacers on the 2 long studs (A & B).6. Place the upstacker bill validator over the 4 studs with spacers on them (A, B, E & F).7. Place ground wire coming from the bill validator unit on the ground stud.8/ Secure hex nuts (A, B, E & F) removed in steps #1 and #2.
